Mechanical Specifications |
Model |
ATO-PSFP-500 |
Solar Cell |
Monocrystalline |
Surface Material |
ETFE |
Cloth Color |
Black |
Open Size |
3120 x 1100mm |
Folding Size |
570 x 550mm |
No. of Folding |
10 = 2 * 5 |
Net Weight |
10.5 KG |
Type of Connector |
XT60 + Anderson + GX16 + DC |
Additional Design |
Kickstands |
Certifications |
CE, FCC, ROHS, REACH |
Electrical Specifications |
Standard Test Condtion |
Irrandiance 1000W/m2, Module temperature 25℃, AM=1.5 |
Maximum Power (Pm) |
500W |
Voltage at Max Power (Vmp) |
18V |
Current at Max Power (Imp) |
27.8A |
Open Circuit Voltage (Voc) |
21.6V |
Short Circuit Current (Isc) |
30.3A |
Temperature Coefficient of Pmax |
(-0.41% /ºC) |
Temperature Coefficient of Voc |
(-0.33% /ºC) |
Temperature Coefficient of Isc |
(+0.06% /ºC) |
Other Performance Datas |
Power Tolerance |
-0%, +5% |
Maximum System Voltage |
1500V DC |
Maximum Series Fuse Rating |
35A |
Operating Temperature |
-20℃~65℃ |
Normal Operating Cell Temperature (NOCT) |
45℃ ± 2℃ |
Warranty |
2 years limited product warranty on materials and workmanship. |
Power is not less than 80% in 5 years. |
